Dry Pet Food Extrusion Line

Share

Dry Pet Food Extrusion Line could produce different kinds of dry pet food for dog, cat, fish, fox, bird, horse, etc.

The pet food factory is a fully automatic pet food production line for cat food and dog food. It is mainly composed of raw material processing system, extrusion system, drying system, seasoning system and control system. This pet food production line has high stability and automation performance, and can control the expansion of the extrudate in a variety of ways. Refers to controlling the texture of the final product. The machines are all made of stainless steel. The dog food production line has a reasonable design and a high degree of automation. The screw is made of alloy steel and has a modular structure with a self-cleaning function.

The production line equipment has reasonable design, high degree of automation, precise control of extrusion process parameters, and innovative design of the temperature controller, which further improves the maturation effect of the feed.

The pet food production line uses high-strength corn flour grains as the basic raw material, supplemented by bone meal, meat, protein, vitamins, fiber and other nutrients, and cooperates with a screw extruder to produce pet dog food of different shapes through strong extrusion. Extrusion and instant expansion molding. Cat food and other pellet feeds, and also produces aquatic feed floating feed, mackerel pellet feed, goldfish pellet feed, shrimp pellet feed, crab, mud, bullfrog and other feed and food. The dry flavor coating enhances the taste of the final product, and the final set is automatically packaged. The particle size can be from 0.9-15mm to feed fish of different sizes. Our pet food production line has high output and high product quality. It is the first choice for large and medium-sized feed processing plants, aquaculture farms, and pet food industries.

The pet food production line gives pet food novel shapes, unique tastes and colors, scientific nutritional ratios, and easy digestion to adapt to the growing pet food market. There are various flavors and shapes to meet the needs of all kinds of pet food. The pet food production line consists of powder mixing, twin-screw extruder, air flow machine, drying and seasoning lines.




Introducing the pet food extruding production line, an advanced and fully automated system designed to revolutionize the pet food industry. Engineered to meet the growing demands of pet owners, this production line ensures the creation of high-quality and nutritious pet food products that will keep pets healthy and satisfied. Whether you're manufacturing dog food, cat food, fish feed, or other animal feed products, this state-of-the-art production line is your gateway to success.


Advantages:

Unparalleled Efficiency

Our pet food extruder operates seamlessly, allowing for continuous production and impressive output capacity. Say goodbye to bottlenecks and maximize your productivity.

Tailored to Perfection

We understand that pets have unique dietary needs and preferences. That's why our pet food production line offers unrivaled customization options. From different recipes and flavors to diverse shapes and sizes, you can cater to the specific requirements of every pet.

Consistent Quality, Every Time

With our extrusion process, you can rest assured that the quality and texture of your pet food will be consistently exceptional. The carefully controlled extrusion ensures that the nutritional value of the ingredients remains intact, providing pets with the nourishment they need.

Extended Shelf Life

Our pet food processing line incorporates drying and cooling processes that contribute to preserving the freshness and extending the shelf life of your pet food products. Give pet owners peace of mind knowing that the food they purchase for their beloved pets remains wholesome and delicious.

User-Friendly Operation and Maintenance

We believe in simplifying processes without compromising results. Our modern pet food production lines are designed with user-friendly interfaces, making operation a breeze. Additionally, the easy-to-clean components reduce downtime and labor costs, allowing you to focus on what matters most: creating exceptional pet food products.


Investing in the Pet Food Extruding Production Line means investing in the future of your pet food manufacturing business. Stay ahead of the competition, meet the demands of pet owners, and deliver high-quality, nutritious, and palatable pet food products that pets will love. Don't miss out on this opportunity to elevate your production capabilities and take your pet food business to new heights.


Contact us today to discuss how the Pet Food Extruding Production Line can be customized to meet your specific needs and requirements. Let us help you achieve unparalleled success in the pet food industry, one nutritious and delicious pet meal at a time.

contact us


Flow Chart

Dry Pet Food Extrusion Line

How is pet food produced?

Typical raw materials used in pet food processing include grain meal, vegetable proteins, minerals and vitamins, and in some cases meat or fish meal and fresh meat. The dry material enters the preconditioner+ and undergoes steam hydration. The blender mixes the ingredients and ensures that the steam, moisture and ingredients are mixed properly. Pretreatment produces partial gelatinization of the starch and structure of the polymer. The parboiled mixture is then fed to a twin-screw extruder where shear, internal temperature, pressure, moisture and residence time are precisely controlled to achieve optimal starch gelatinization without loss of food quality. At different processing stages, liquid or steam can be injected through ports in the extruder barrel. Vent packing can be used for degassing at this stage.


Pet food production line production process

1. Mix

The mixing process is a key process in pet food production. The basic process is to weigh raw materials of different weights according to the formula, then pour them into the crusher for crushing, and then temporarily store all the raw materials in the storage silo. Then all the ingredients are ready and blended in a blender.

2. squeeze

Extrusion is a high-temperature, short-time heat treatment process. It not only reduces the degradation of food nutrients and improves protein and starch digestibility, but also destroys anti-nutrients and microorganisms. Dry pet food in round, triangular, flower-shaped, bone-shaped and other shapes can be produced through different molds (templates) of the feed extruder. In pet food production, fat is often added to improve the palatability of the pet food, which is done during the conditioning process. Additionally, in order to give pet food tablets different colors, manufacturers often add pigmented water to the extrusion chamber.

3. Dry

The drying part is mainly used to remove moisture from puffed pet food. The extruded material has a soft texture and a moisture content of 20-30%. After drying, the moisture of the finished product is controlled at 8%~10%, which can ensure the storage of the materials within a certain period of time.

4. Add grease

Oil is the best source of energy, so 2%-40% oil can be added to the formula according to the pet's growth needs. We recommend that the fat content in the formula, i.e. the total oil content in the extruder, should be kept within 12%. If the oil content is required to exceed 12%, the hardness of the particles will be significantly reduced. If the extruded material needs to contain more than 12% oil, it is recommended to add oil after drying. Can be used under normal pressure or vacuum spraying, depending on the amount of oil added. Exterior spray will give the pet food tablets a more attractive appearance. In addition to oil, some powdered attractants are also sprayed to increase the palatability of pet feed.

5. Cooling and screening

The main function of the cooling section is to cool the dried materials from high temperature to near room temperature and take away part of the moisture. Additionally, substandard food tablets will be separated from qualified food products during this process.

Layout

Dry Pet Food Extrusion Line

Extruder’s Structure

Dry Pet Food Extrusion Line

Technical Parameters


Model

Capacity

Power

Dimension

QL-65

120-150kg/hr

52kw

25 x 5 x 3m

QL-70

200-300kg/hr

86kw

28 x 5 x 3m

QL-85

500-800kg/hr

140kw

32 x 5 x 3m

QL-90

1000-1500kg/hr

180kw

40 x 10 x 8m

QL-95

2000-2500kg/hr

220kw

60 x 15 x 12m

QL-120

3000-3500kg/hr

300kw

80 x 20 x 16m

QL-135

4000-5000kg/hr

400kw

100 x 20 x 16m


Main Equipment List


I. Flour Mixer or Ribbon Mixer

The raw materials, such as grains, proteins, vitamins, and minerals, are combined and mixed evenly in a mixing machine to create a homogenous blend.

Dry Pet Food Extrusion Line

II. Screw Conveyor or Scraper Conveyor

The mixed materials are transferred to the extruder using a conveyor, such as a screw conveyor or a Scraper Conveyor

Dry Pet Food Extrusion Line

III. Double Screw Extruder

The core component of the production line, the extruder processes the mixed materials by applying heat, pressure, and mechanical shearing. This causes the materials to undergo various physicochemical changes, resulting in the formation of a dough-like mass. The extruder then pushes this mass through a die, creating the desired shape and size of the pet food.

Dry Pet Food Extrusion Line

IV. Vibrating Sifter

Vibrating Sifter is a conveyor. It uses to convey the raw material to next equipment, and at the same time, it sifts to prevent the raw materials sticking together.

Dry Pet Food Extrusion Line

V. Air Conveyor

Air Conveyor is responsible to convey the materials to the next equipment. There equipped with a blower to blow the materials.

Dry Pet Food Extrusion Line

VI. Multi-layer Roaster

The extruded pet food is then passed through a drying system, such as a multi-layer dryer or a fluidized bed dryer, to remove excess moisture and achieve the desired texture.

Dry Pet Food Extrusion Line

VII. Flavoring Machine

To enhance the palatability of the pet food, a flavoring system can be employed. This may involve spraying liquid flavors, oils, or powders onto the cooled pet food to make it more appealing to pets.

Dry Pet Food Extrusion Line


Customized Service


1. Customized mold to produce different shape and size.

2. Customized layout as the customer’s actual workshop.

3. Customized motor and electric parts, it can be Siemens ABB OMRON, or LIJIU CHNT DELIXI.

4. Customized recipe as the customer’s requirement.

5. Customized voltage as the local voltage.

6. Customized machine materials, SUS 201, SUS 304, SUS 316.

Dry Pet Food Extrusion Line

Advantages of Pet Food Production Line

1. Precise control of process parameters and automation ensure optimized pellet quality: gelatinization, expansion, consistent texture and quality. These quality standards are achieved because the screw ensures uniform processing and positive pumping. The processing of viscous pastes does not depend on the friction between the screw and barrel. Embedded automatic temperature control and regulation system, modular screw configuration and screw speed are easily programmable to help improve production line performance.

2. Intelligent pet food extruder: formula management (recording, access, supervision), process management (start/stop), sensor installation, control and maintenance. Advanced production line automation helps reduce operating costs and promotes stable nominal production.

3. Use special molds for creative shapes and finishing of products with innovative shapes and different textures (co-extrusion).

4. The composition is flexible and various raw materials with high fat content can be processed as needed.

5. Use standard parts of extrusion and drying equipment to reduce maintenance and facilitate inspection of different machine parts.

6. Specifically designed by our expert engineers with advanced automation features to ensure precise process control for easily reproducible product quality.

7. From 100kg/hour to 2000kg/hour



Company Profile

Dry Pet Food Extrusion Line

Jinan Qunlong Machinery Co., Ltd. (shorten as “Dragons Machine”) is the professional manufacturer of all kinds of Snacks Food Machine and Pet Food Machine. Established in year 2004, Dragons Machine has been more than 18 years history with workshop 5000m2 and more than 60 employees, and certified by ISO 9001. As the council member of Chinese North China Pet Industry Association (CNCPIA), and awarded by the National Quality Service Credit AAA Enterprise, Dragons Machine has several kinds of patented products, and could provide customized service. All the machinery from Dragons Machine have been EU CE certified, and have sold to more than 50 countries around the world, like USA, Australia, France, Lebanon, Thailand, Tunisia, Algeria, Italy, Peru, India, etc.


Factory Show

Dry Pet Food Extrusion Line


Machinery Package & Delivery

Dry Pet Food Extrusion Line


Company Certificate

Dry Pet Food Extrusion Line


Customers & Exhibitions

Dry Pet Food Extrusion Line


Why Us



Who are we?



- We are Dragons Machine, the council member of Chinese North China Pet Industry Association (CNCPIA). We have rich experience in Snacks Food Machine and Pet Food Machine, so we are helpful to each customer.



Why us?



- All machines from Dragons have CE Certificate

- Dragons Machine has been certified by ISO 9001

- Patented machinery with high-level technology


Extruders with Different Models

Dry Pet Food Extrusion Line
