Baby Food Powder Machine

Share

Baby Food Powder Machine produces nutrition powder and baby food, which are used worldwide to nourish young children and are also consumed in many countries as a basic ingredient for regional dishes, such as porridge or soups.


Nutrition Powder Processing Line produces nutrition powder and baby food, which are used worldwide to nourish young children and are also consumed in many countries as a basic ingredient for regional dishes, such as porridge or soups. The process line uses rice,corn, beans, and all kinds of grains as raw material. Through extruding, inflating, drying, crushing, and mixing, it could produce many kinds of nutrition powder, such as baby rice powder, sesame paste,bean powder and so on. This line could finish all the process automatically from feeding to the end. It has features of easy operation, without leak of powder dust, sanitation,saving energy and easy to add all kinds of raw material and nutriment.


-- Advanced double screw extruding technique.
-- Use corn powder, rice powder, and other grain powder as main materials, and other nutritional ingredients can be added.
-- Double screw extruder can also produce other products, like leisure snacks, breakfast cereal, nutritional rice and powder, bread crumb, crispy rice chip, etc.
-- Convenient operation and maintenance, low power consumption, high output are its characteristics.


Work Flow

Baby Food Powder Machine


Layout

Baby Food Powder Machine

Model

Capacity

Power

Dimension

QL-65

120-150kg/hr

52kw

25 x 5 x 3m

QL-70

200-300kg/hr

86kw

28 x 5 x 3m

QL-85

500-800kg/hr

140kw

32 x 5 x 3m


Baby Food Powder Machine


Baby Food Powder Machine

Main Equipment List

I. Flour Mixer or Ribbon Mixer

Mixer is used to add a certain amount of raw materials to a certain amount of water or liquid additives after stirring to reach the full mixing equipment.

Dry Pet Food Extrusion Line


II. Screw Conveyor or Scraper Conveyor

Screw Conveyor or Scraper Conveyor could carry the material inside the sealed stainless steel tube into the feeding machine of the extruder. Without leakage, dust and pollution.

Dry Pet Food Extrusion Line


III. Double Screw Extruder

Double Screw Extruder serves to gelatinize flours and starches continuously and automatically, also cook, shape and cut the materials as required shape and size.

Dry Pet Food Extrusion Line


IV. Vibrating Sifter

Vibrating Sifter is a conveyor. It uses to convey the raw material to next equipment, and at the same time, it sifts to prevent the raw materials sticking together.

Dry Pet Food Extrusion Line


V. Air Conveyor

Air Conveyor is responsible to convey the materials to the next equipment. There equipped with a blower to blow the materials.

Dry Pet Food Extrusion Line


VI. Multi-layer Roaster

Multi-layer Roaster is used to dry the moisture of the products as requirement. The drying time and temperature can be set, and the heating power can be electric, gas or steam.

Dry Pet Food Extrusion Line


VII. Grinding & Blending Machine

Grinding & Blending Machine firstly mill the products to powder as equired size, then blend with other nutritional substitutes.

Baby Food Powder Machine


Customized Service


1. Customized mold to produce different shape and size.

2. Customized layout as the customer’s actual workshop.

3. Customized motor and electric parts, it can be Siemens ABB OMRON, or LIJIU CHNT DELIXI.

4. Customized recipe as the customer’s requirement.

5. Customized voltage as the local voltage.

6. Customized machine materials, SUS 201, SUS 304, SUS 316.

Company Profile

Fortified Rice Processing Line


Jinan Qunlong Machinery Co., Ltd. (shorten as “Dragons Machine”) is the professional manufacturer of all kinds of Snacks Food Machine and Pet Food Machine. Established in year 2004, Dragons Machine has been more than 18 years history with workshop 5000m2 and more than 60 employees, and certified by ISO 9001. As the council member of Chinese North China Pet Industry Association (CNCPIA), and awarded by the National Quality Service Credit AAA Enterprise, Dragons Machine has several kinds of patented products, and could provide customized service. All the machinery from Dragons Machine have been EU CE certified, and have sold to more than 50 countries around the world, like USA, Australia, France, Lebanon, Thailand, Tunisia, Algeria, Italy, Peru, India, etc.


Factory Show

Fortified Rice Processing Line


Machinery Package & Delivery

Fortified Rice Processing Line



Company Certificate

Fortified Rice Processing Line


Customers & Exhibitions

Fortified Rice Processing Line
